The envy of your server room

BUILD YOURS
  • UP TO 22 USERS

    Direct

  • 10GB/1GB

    Connectivity

  • 80TB-240TB

    Raw Storage

  • 4x

    Expandability

LumaForge Jellyfish Rack product image

CONNECTIVITY

Plug & play, switch optional

Jellyfish Rack can be used with or without a switch. Users can connect directly into one of the up to 22 onboard 1GbE or 10GbE ports, or add a switch for greater expansion. There is no limit to the number of users connected simultaneously.

LumaForge Jellyfish connectivity spec icon 1gbe 10gbe LumaForge Jellyfish connectivity spec icon 25 40 50 gbe LumaForge Jellyfish connectivity spec icon 22 users

STORAGE

5 capacity points to choose with room to grow

Jellyfish Racks are listed with a raw capacity number and a Working Space number. Working Space is what’s actually available for storage after RAID, performance buffers, and overhead are applied.

Working Space

Number of Expansions

PERFORMANCE

A bandwidth beast in 4U

Jellyfish Rack is the workhorse of the modern video team. It makes quick work of the most demanding RAW workflows, multicam sequences, and finishing jobs, which means you can say yes to anything thrown your way.

Number of Expansions

SETUP & SOFTWARE

lumaforge jellyfish setup guide software

SETUP IS SIMPLE

Jellyfish Rack was designed to be unboxed and up and running in under 30 minutes with no prior networking experience required. You will be guided through each step of the setup online, and if you need additional help our support team is only a phone call away.

JELLFISH MANAGER

If you HAVE NEVER had to manage a server before, we designed the Jellyfish Manager for you. If you HAVE managed a server before, you’ll wonder why they all weren’t this easy and intuitive.

lumaforge jellyfish manager menu on imac computer
lumaforge jellyfish connect app preview on imac computer

JELLYFISH CONNECT

We’ve made connecting your Mac to the Jellyfish Rack easier than ever with our patented Jellyfish Connect app for macOS. Just open the app on your computer, let it work its magic, and get right to work.

operating systems compatible with the lumaforge jellyfish

OS COMPATIBILITY

Jellyfish Rack is compatible with Mac, Windows, and Linux operating systems and supports a mixed hardware / software environment.

Supported nle non linear editing applications for the lumaforge jellyfish

NLE COMPATIBILITY

Work in the NLE, DAW, or VFX software of your choosing, or use them all. Our engineers works closely with Apple, Adobe, and Blackmagic to ensure seamless workflows between your favorite apps.

VIDEOS

DEEP SPECS

USERS & CONNECTIVITY

MAXIMUM DIRECT CONNECTIONS

22

SWITCH REQUIRED

No

THUNDERBOLT CONNECTIVITY

With third party Ethernet to Thunderbolt adapter

STANDARD CONNECTIVITY

10 Gigabit Ethernet

1 Gigabit Ethernet

via RJ45 [CAT5/6/6a/7 Cables]

BASE CONFIG.

2 x 10GbE RJ45 ports

CONNECTION UPGRADES

ADD 10GbE [RJ45 // SFP+]

ADD 25GbE [QSFP]

ADD 40GbE [QSFP]

ADD 50GbE [QSFP]

STORAGE

AVAILABLE CAPACITY

80TB, 120TB, 106TB, 200TB, 240TB

USABLE STORAGE SIZE

53TB, 79TB, 106TB, 132TB, 159TB

EXPANDABILITY

Add up to 4 additional Jellyfish Rack expansion units anytime over the included 12G HD Mini-SAS port.

PERFORMANCE

AGGREGATE BANDWIDTH

4200MB/s Read

2400MB/s Write

PER USER SPEEDS

25GbE User - 1000-1700MB/s

10GbE User - 650-1000MB/s

1GbE User - 100MB/s

BOOST SPEEDS

Double RAM Cache

Ingest Capacitor

DATA SECURITY

SOFTWARE RAID PROTECTION

All Jellyfish utilize a software RAID which adds an extra layer of protection to your data since all data and metadata are stored on your pool.

STANDARD SOFTWARE RAID 6

By default the Jellyfish Rack can sustain the failure of up to 2 hard drives per 10-disk virtual device, up to a maximum simultaneous failure of 4 physical drives per pool.

BACKUP & ARCHIVE

Rsync

Snapshots

PHYSICAL SPECS

DIMENSIONS

Height 7 inches

Depth 27 inches

Width 19 inches

Weight 90 lbs.

FORM FACTOR

Rack - 4U

MAX NOISE LEVEL

~71 Decibels Under Heavy I/O

POWER SUPPLY

100-240V~12-6A 50-60Hz

1000 Watt

Average Power Draw: ~650W

ADDITIONAL SERVER ACCESS

IPMI

USB 3 [x4]

VGA PORT

PROTOCOL SUPPORT

SMB

NFS

sFTP

SSH

MISC.

Compatible with Active Directory / Open Directory

Integrated DaVinci Resolve Collaborative Database

Encryption Options Available
